Create Hole Patterns with Unittool Tooling

Create Hole Patterns with Unittool Tooling

Are you looking to streamline your hole punching and part notching processes? Look no further than Unittool. Our innovative tooling system offers a range of units that can be used together to create precise hole patterns and edge notches, making the production of parts faster and more efficient.

Create a Hole Pattern in Parts

The Unittool system is designed to simplify the creation of hole patterns. With its c-frame casting and precisely aligned punch and die, you can achieve accurate results. The key to creating the desired hole pattern is the round pilot pin located at the bottom of the unit. By inserting it into the designated hole in the mounting system, such as a mounting template, you can easily achieve the desired outcome.

But what if you require a shaped hole? Unittool has got you covered. An additional diamond pilot pin, also known as an orientation pin, maintains the orientation of the shape within the hole pattern. This ensures consistency across multiple batches of parts. The Unittool system empowers you to create complex hole patterns without sacrificing accuracy or efficiency.

Embrace Unittool for Enhanced Efficiency

The Unittool system offers a host of advantages that can significantly enhance your manufacturing processes. Its ability to create precise hole patterns, combined with its rapid setup time and increased production speed, make it a game-changer for businesses aiming to improve efficiency and productivity.



Whether you are looking to streamline your existing operations or stay ahead of the competition, Unittool can help you achieve your goals. Say goodbye to tedious setups and hello to a more efficient and productive future.
